Felix SINGLE


Large format single sided XY Glue Plotter Table

Introducing Felix SINGLE

Felix SINGLE is a large format XY Glue Plotter Table, it’s available in a range of sizes from 1650mm x 1250mm (65 x 49 in.) up to 2500mm x 1800mm (98 x 70 in.). The motor driven worktable of the machine lowers up to 500mm (20 in.) for stacking of materials to maximise gluing productivity. Up to two operators can use the machine at one time and multiple jobs can be glued in the work area of the machine simultaneously. Both hot melt and cold PVA glues can be applied with extreme position in bead, microdot and/or spray application modes.


    Range of different table sizes available (see further down page)


    Apply hot melt and/or cold PVA glues


    Bead, microdot and spray glue application modes


    Glue application speeds up to 2.5m/s (8.2ft/s)


    Elevating work table for stacking of materials


Video demonstration

Applications

The Felix automatic CNC glue application machine is widely used in the print, point of sale (POS) and packaging industry, however it is not just limited to these markets. Commonly glued items include corrugated boxes, free standing display units, dump bins, and much more! With the machine being able to apply both hot melt and cold (PVA) glue simultaneously, the possibilities are endless. Apply glues to almost any type of material, in any shape!


    Corrugated POS/POP displays (FSDUs, CDUs, dump bins)


    Standard or bespoke corrugated cartons


    Foam for packaging, insulation or acoustics


    Expanded polystyrene for packaging, insulation and construction


    Specific niche industry applications, talk to us!

Available Table Sizes:

SMALL


1650mm x 1250mm



REGULAR


2000mm x 1650mm



LARGE


2200mm x 1800mm



XL


2500mm x 1800mm



Specification:

Machine Speed 2.5 meters per second
Glue Heads OptionsHotmelt and/or Cold (PVA)
Hotmelt Glue Application ModesLines, dots or swirl spray
Cold (PVA) Glue Application ModesLines, dots or spray
Software LanguageEnglish or Polish
Electrical Needs 240v, 50Hz (other options available on request)
Number of Workspaces Up to 2 fully independent work spaces
Program Memory Unlimited
Work Table System Integrated automatic elevating work bed
Maximum Material Stack Height 500mm - 900mm
Glue System Options Meler, Nordson, UES or Zator
Compressed Air Requirements 6 Bar
Modem for Remote Assistance Integrated as standard
Warranty Period 12 months
Price Please contact us for pricing
